<%@LANGUAGE="JAVASCRIPT" CODEPAGE="936"%> Tuner: Antel Electronics Co., Ltd.



SYSTEM VHFL VHFH UHF PIF SIF POWER GAIN
CCIR 1A-S9 S10-S40 S41-E69 38.9MHz 33.4MHz 30dB MIN



Pin No. 1 2 3 4 5 6 7 8 9 10 11
Function AGC VT B3 B2 B1 BM NC NC NC NC IF
Voltage 7V 0-30V 0/9V 0/9V 0/9V 9V - - - - -
