SYSTEM VHFL VHFH UHF PIF SIF POWER GAIN
U.S.A.181Channel 2-B C-W+11 W+12-69 45.75MHz 41.25MHz 30dB MIN



Pin No. 1 2 3 4 5 6 7 8 9 ii ii
Function ENB SDA SCL 5V 30V IF 12V AFC NC ii ii
Voltage - - - 5V 30V - 12V - - ii ii
