<%@LANGUAGE="JAVASCRIPT" CODEPAGE="936"%> Tuner: Antel Electronics Co., Ltd.



SYSTEM VHFL VHFH UHF PIF SIF POWER GAIN
DK/BG 46MHz-170MHz 170MHz-460MHz 460MHz-870MHz 38MHz/38.9MHz 31.5/32.4MHz 30dB MIN



Pin No. 1 2 3 4 5 6 7 8 9 10 11
Function AGC VT AS SCL SDA NC 5V AFC 33V NC IF
Voltage - - - - - - 5V - 33V - -
