| Code: | Silcon Rectifier |  |
| Name: |
 |
| Item No. | Max peak Rectified voltage | Max Average Rectified Current | 6Max Forward Peak Surge Current | Max reverse Current | Max Forward Current | Max Forward Voltage |
| V pk=V | Io=A | I fm=A | Ir=uA | I fm=UA | V fm=V | |
| 1N4001 | 50 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4002 | 100 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4003 | 200 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4004 | 400 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4005 | 600 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4006 | 800 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| 1N4007 | 1000 | 1.0 | 30 | 5.0 | 1.0 | 1.0 |
| BY127 | 1250 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| BY133 | 1300 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL101 | 50 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL102 | 100 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL103 | 200 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL104 | 400 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL105 | 600 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL106 | 800 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| RL107 | 1000 | 1.0 | 30 | 5.0 | 1.0 | 1.1 |
| 1N5391 | 50 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5392 | 100 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5393 | 200 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5394 | 300 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5395 | 400 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5396 | 500 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5397 | 600 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5398 | 800 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| 1N5399 | 1000 | 1.5 | 50 | 5.0 | 1.5 | 1.1 |
| RL151 | 50 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL152 | 100 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL153 | 200 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL154 | 400 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL155 | 600 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL156 | 800 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL157 | 1000 | 1.5 | 60 | 5.0 | 1.5 | 1.1 |
| RL201 | 50 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL202 | 100 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL203 | 200 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL204 | 400 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL205 | 600 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL206 | 800 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL207 | 1000 | 2.0 | 70 | 5.0 | 2.0 | 1.0 |
| RL251 | 50 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL252 | 100 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL253 | 200 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL254 | 400 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL255 | 600 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL256 | 800 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| RL257 | 1000 | 2.5 | 150 | 5.0 | 2.5 | 1.0 |
| 1N5400 | 50 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5401 | 100 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5402 | 200 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5404 | 400 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5406 | 600 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5407 | 800 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| 1N5408 | 1000 | 3.0 | 200 | 5.0 | 3.0 | 1.0 |
| BY251 | 200 | 3.0 | 150 | 5.0 | 3.0 | 1.1 |
| BY252 | 400 | 3.0 | 150 | 5.0 | 3.0 | 1.1 |
| BY253 | 600 | 3.0 | 150 | 5.0 | 3.0 | 1.1 |
| BY254 | 800 | 3.0 | 150 | 5.0 | 3.0 | 1.1 |
| BY255 | 1300 | 3.0 | 150 | 5.0 | 3.0 | 1.1 |
| 6A05 | 50 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A1 | 100 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A2 | 200 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A4 | 400 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A6 | 600 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A8 | 800 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
| 6A10 | 1000 | 6.0 | 400 | 5.0 | 6.0 | 0.95 |
