FEATURES:

● 19” single rack space

● Four inputs,eight outputs

● Extremely intuitive user interface

● Crossover,EQ,delay and limiter functions

● Outputs assignable to any input

● Superior sonic quality

● Front panel,PC or MIDI programming and control

● Third party control friendly

● XLR audio connections

● Balanced inputs and outputs

● Parametric filters and comp/limiter to control feedback problems

● Linkwitz-riley,bessel and butterworth filters

● 12,18,24 and 48dB/octave slopes

● Parametric EQ:1/64th to 4 octave range

● Input and output delay

● Limiter on each output

● Individual input and output metering

● Four levels of security

 SPECIFICATIONS:

● Input:Active Balanced,18KΩ

● Input Max Level:+20dBu

● Input Gain Range:-40dB ~ +12dB

● Output:Active Balanced,112Ω

● Output Max Level:+20dBu

● Output Gain Range:-40dB ~ +12dB

● EQ Filter Types:1st or 2nd Order High or Low Shelf, Parametric

● EQ Shelving Filter Boost/Cut Range: ±15dB

● EQ Shelving Filter Frequency Range: Low Shelf 19.7Hz~2kHz, High Shelf 3.8kHz~21.9kHz

● EQ Filter Boost/Cut Range:+15dB/-30dB

● EQ Filter Frequency Range:19.7Hz~21.9kHz,1/24 Octave Steps

● EQ Filter Bandwidth:Four Octaves to 1/64 Octave

● Delay Input Delay:0-682 milliseconds

● Delay Output Delay:0~21.3 milliseconds

● Limiter Threshold Range:-20dBu to +20 dBu

● Frequency Response:20Hz~20KHz, ±0.25dB

● THD:<0.01% @ 1KHz,+20dBu

● Dynamic Range:>110dB 20Hz~20KHz unweighted

● Audio Sampling Rate:48KHz

● Propagation Delay:1.46mS

● Power Supply:AC220V 50Hz
