FEATURES:

● 19” 1.5U rack space

● Adopt double 24-bit high level DSP, 48 KHz sampling frequency

● MIC input & Music input channel is setup with 7 bands EQ Separately

● Main output is setup with 15 bands EQ

● Center & Subwoofer output is setup with 3 band EQ

● Crossover of subwoofer: HPF 0~100Hz, LPF 0~300Hz

● Can switch the hot-dancing mode automatically when the MIC cut OFF

● Main voice center output (Reverberation & direct sound rate can be adjusted separately) and post patch output (Post volume can be adjusted separately, MAX delay time is 50ms) are available

● 20 modes have been pre-stored; mode name & content can be changed automatically

● Inside set up project mode and customer mode: customer mode is unavailable to be saved after changing the parameter

● Automatically lock the keys (not able to change after lock except volume)

● Set up with full effect function menu, can be adjusted by software of PC as well

● Automatic digital feedback eliminator, sound enhancer

● ±5 grades stereo music can be changed, and can be reset to the original adjustment

 SPECIFICATIONS:

● Input:Unbalanced,20kΩ

● Input Max Level:+5dBu

● Input Gain Range:-30dB to +12dB

● Output:Balanced,120Ω

● Output Max Level:+20dBu

● Output Gain Range:-30dB to +12dB

● Music Channel Gain:>12dB

● Microphone Sensitivity:64mV(Out:3.5V)

● S/N(dB):80dB

● Music Frequency Response:20Hz~20kHz(+1dB)

● The adjustment of music sound quality

Bass adjustment:100Hz(±)10dB

Mid adjustment:1Hz(±)10dB

Treble adjustment:10Hz(±)10dB

● The adjustment of microphone sound quality

Bass adjustment:100Hz(±)10dB

Mid adjustment:1Hz(±)10dB

Treble adjustment:10Hz(±)10dB

● Power Supply:AC220V 50Hz
