FEATURES
● 4 channels stereo DJ mixer
● 8 Line/2 Phono/2 MIC input select
● AMP, Booth and REC output
● Dual bands 10 digits LED level display
● Dual 10-band graphic equalizer
● Built-in 6 effects and Echo, effects volume and speed are adjustable
● Assignable cross fader
● Talk over function
● DC12V BNC lamp jack
INPUT LEVEL
● MIC1:1.5mV/600Ω balanced
● MIC2:1.5mV/600Ω unbalanced
● Phono:3mV/50kΩ
● Line:150mV/27KΩ
OUTPUT LEVEL
● Master:2V/10kΩ
● Record:2V/10kΩ
MIC EQ CONTROL
● High:10kHz/±12dB
● Low:80Hz/±12dB
