FEATURES
● DJ mixer
● 4 Line/2 Phono/1 MIC input
● Master and REC output
● Dual pointer gauge level display
● 5-bands graphic equalizers
● Independent monitor
● Talkover
INPUT LEVEL
● MIC:1.5mV/600Ω balanced
● Phono:3mV/50kΩ
● Line:150mV/27KΩ
OUTPUT LEVEL
● Master:2V/10kΩ
● Record:2V/10kΩ
