| Code: | PA300 PA500 PA600 PA700 PA800 PA1000 PA1500 |  |
| Name: | professional amplifier PA series |
 |
Features:
● Reliable and stable amplifier PA300~PA700 class AB circuit, Toshiba transistor PA800~PA1500 class H circuit, Sanken transistor
● 3U steel chassis,250W~1200W power output
● Perfect protection circuit such as over heat, over load, short-cut protection, anti-shock and DC output protection
● Turn on delaying and turn off soundless
Specifications:
| Model | PA300/CS-1000 | PA500/CS-2000 | PA600 | PA700/CS-3000 | |
| Power output (W) 1KHz,0.5%THD+N |
Stereo 8Ω | 250W | 350W | 500W | 650W |
| Stereo 4Ω | 400W | 500W | 800W | 950W | |
| Bridged Mono 8Ω | 650W | 900W | 1250W | 1650W | |
| Frequency response(1W@8Ω) | 20Hz-20kHz +0/-0.3dB | ||||
| THD+N(Continuous power, 8Ω/1kHz) | ≤0.05% | ||||
| S/N rate (20Hz-20kHz full load) | ≥105dB | ||||
| Slew rate | 100V/us | ||||
| Damping factor | ≥400:1 | ||||
| Cross talk | ≥70dB | ||||
| Input impedance | 20KΩ(Balance) /10KΩ(Unbalance) | ||||
| Input sensitivity | 0.775V/1.0V/1.44V | ||||
| CMRR | ≥63dB | ≥62dB | ≥60dB | ||
| Voltage gain(@1.44V/1V/0.775V) | 34X/44X/57X | 36X/53X/68X | 43X/63X/81X | 50X/72X/93X | |
| Input compression ratio | 18:1 | ||||
| Dimension(WxDxH) | 483(19")mmx420mmx133(3U)mm | ||||
| Weight | 18Kg | 19.8kg | 22.5kg | 23.5kg | |
| Model | PA800/CS-4000 | PA1000 | PA1500 | |
| Power output (W) 1KHz,0.5%THD+N |
Stereo 8Ω | 800W | 1000W | 1200W |
| Stereo 4Ω | 1300W | 1600W | 2000W | |
| Bridged Mono 8Ω | 2000W | 2500W | 3000W | |
| Frequency response(1W@8Ω) | 20Hz-20kHz +0/-0.3dB | |||
| THD+N(Continuous power, 8Ω/1kHz) | ≤0.05% | |||
| S/N rate (20Hz-20kHz full load) | ≥105dB | |||
| Slew rate | 100V/us | |||
| Damping factor | ≥300:1 | |||
| Cross talk | ≥70dB | |||
| Input impedance | 20KΩ(Balance) /10KΩ(Unbalance) | |||
| Input sensitivity | 0.775V/1.0V/1.44V | |||
| CMRR | ≥57dB | ≥56dB | ||
| Voltage gain(@1.44V/1V/0.775V) | 50X/80X/103X | 62X/89X/115X | 68X/98X/126X | |
| Input compression ratio | 20:1 | |||
| Dimension(WxDxH) | 483(19")mmx485mmx133(3U)mm | |||
| Weight | 32.9kg | 33.8kg | 37.5kg | |
