FEATURES:

● 19” single rack space

● 318 DSP digital display effector

● 24-bit digital signal processing plus 20-bit A/D and D/A conversions

● Programs include: reverb, delay, echo, flange and effect combinations

● Easy-to-read 2-digit LED display

● Auto-bypass when power is off

● Balanced inputs and outputs on 1/4" TRS and XLR connectors

● MIDI Connector for computerized programming

● Low distortion & low noise processing

● Bi-color peak LEDs for easy input level-setting

● Internal shielded transformer

● Compact and durable all-steel chassis design

 SPECIFICATIONS:

● Input Connector:XLR and 1/4" TRS jack

● Input Type:Servo balanced input,RF filtered

● Input Impedance:Balanced 60kΩ,unbalanced 30k

● Input Max Level:-90dB to 10dB

● Output Impedance:Balanced 600Ω,unbalanced 300Ω

● Output Max Level:-120dB to 4dB

● Frequency Response:20Hz~20kHz,0/-3dB

● S/N:≥94dB,22Hz to 22kHz

● Distortion:Less than 0.01%(1kHz

● Band Width:0Hz~20kHz,-30dB

● MIDI Interface Type:5-PIN-DIN socket,I/OUT/THRU

● Digital Processing Sampling Rate:44.1kHz

● Digital Processing A/D&D/A Converters:20-bit Sigma-Delta 64/128-times oversampling

● Power Supply:AC220V 50Hz
