| SH1812 |
|
| 1*12" Two-Way Full Range Passive/Bi-amp Speaker |
| |
|
|
| Applications |
|
| ★ |
Main speaker for auditorium,conference,theate,multipurpose. |
| ★ |
Main/fill in disco and club. |
| ★ |
Portable main,stage monitoring and LR fill in FOH. |
| |
|
|
| Specifications |
|
| |
Frequency response |
60Hz-16KHz (±3dB) |
| |
|
45Hz-18KHz (-10dB) |
| |
Sensitivity (1W/1m) |
HF:107dB LF:97dB |
| |
Nominal impedance |
8Ω |
| |
Power rated (AES) |
HF:75W LF:350W |
| |
Dispersion (HxV) |
80°*50° rotatable |
| |
Crossover |
1.6KHz |
| |
HF |
Tianium diaphragm neodymium magnet |
| |
|
compression driver |
| |
LF |
12"/75mm voice coil/75w |
| |
SPL |
HF:126dB continuous,132dB peak |
| |
|
LF:121dB contiuous,127dB peak |
| |
Connector |
2NEUTRIK NL4MP Passive:1+1-,Bi-amp:(HF)2+2-/(LF)1+1- |
| |
Bi-amp |
1+1- |
| |
Passive |
(HF)2+2- (LF)1+1- |
| |
Fittings |
M10*8 |
| |
Dimension (w*D*H) |
370*323*637mm |
| |
Weight |
24kg |
