FEATURES:

● 19” single rack space

● Error proof operation to smooth uneven levels, add sustain to guitars, fatten drums or tighten up mixes

● New gate timing algorithms ensure the smoothest release characteristics

● Program-adaptive expander/gates

● Great sounding dynamics control for any type of program material

● Separate precision LED displays for gain reduction, compression threshold and gate threshold allow quick, accurate setup

● Stereo or dual-mono operation

● Balanced inputs and outputs on 1/4" TRS and XLR connectors

● Side Chain insert

● Classic "Auto" mode

● Internal shielded transformer

● Compact and durable all-steel chassis design

 SPECIFICATIONS:

● Input Connector:1/4" TRS,female XLR (pin 2 hot)

● Input Type:Electronically balanced/unbalanced,RF filtered

● Input Impedance:Balanced 50kΩ,unbalanced 25k

● Input Max Level:+24dBu,Balanced or Unbalanced

● Output Impedance:Balanced 120Ω,unbalanced 60Ω

● Output Max Level:+21dBu

● Frequency Response:20Hz~ 20kHz,+0/-0.5dB,Typical 3dB points are 0.35Hz and 110kHz,unity gain

● Noise:<-90dBu,22Hz~22kHz,no weighting,unity gain

● THD+N:Typically<0.04%(1kHz)

●Compression Ratio:Variable; 1:1 to Infinity:1; 60dB Maximum compression

● Threshold Range:-40dBu ~ +20dBu

● Threshold Characteristic:Selectable OverEasy® or hard knee

● Attack Time:Variable program-dependent; 3ms~340ms for 15dB gain reduction

● Release Time:Variable program-dependent; 200dB/Sec to 3dB/Sec

● Power Supply:AC220V 50Hz
