| Code: | ICSN-32P |  |
| Name: | IC socket, pitch=1.778mm, 32pin, w/o central support |
 |
Specifications:
| Art No. | Position | A (mm) | B (mm) | C (mm) | D (mm) |
| ICSN-24P | 24pin | 21.34 | 19.56 | 12.65 | 10.16 |
| ICSN-28P | 28pin | 24.89 | 23.11 | 12.65 | 10.16 |
| ICSN-30P | 30pin | 26.67 | 24.89 | 12.65 | 10.16 |
| ICSN-32P | 32pin | 27.45 | 26.67 | 12.65 | 10.16 |
| ICSN-40P | 40pin | 35.56 | 33.78 | 17.73 | 15.24 |
| ICSN-42P | 42pin | 37.34 | 35.56 | 17.73 | 15.24 |
| ICSN-48P | 48pin | 42.67 | 40.89 | 17.73 | 15.24 |
| ICSN-52P | 52pin | 46.23 | 44.45 | 17.73 | 15.24 |
| ICSN-54P | 54pin | 48.20 | 46.20 | 17.73 | 15.24 |
| ICSN-56P | 56pin | 49.78 | 48.01 | 17.73 | 15.24 |
| ICSN-64P | 64pin | 56.90 | 55.12 | 21.54 | 19.05 |
| ICSN-64P-02 | 64pin | 57.18 | 55.11 | 17.73 | 15.24 |
