| Code: | WM-801B |  |
| Name: |
|
| ||
|
WM-801B | ||
| Receiver | System | Transmitter |
|
Sensitivity (S/N=30dB): <2μV Image Rejection: >40dB De-Emphasis: 50μS Audio Output Impedance: 600Ω Audio Output Level: 0-0.5V Power Supply: AA1.5V Batt Dimensions: 100*45*15mm Weight: Appr.37g |
Audio Frequency Response: 50-12500Hz Dynamic Range: ≥60dB System Distortion: ≤1% Signal-to-Noise Ratio: ≥60dB Operating Range: Appr.50M Operating Temperature Range: 5℃-45℃ Carrier Frequency Range: 70-85MHz |
Frequency Stability: ±0.005% RF Output Power: ≤10mW Spurious Rejection: >30dB Modulation Mode: FM Max Deviation Range: ±75KHz Microphone Mode: Electric Condenser Pre-Emphasis: 50μS Power Supply: AA1.5V Batt Current Consumption: <40mA Dimensions: Φ70*45*30mm Weight: Appr.39g(No Batt.) |
