Overall System

Receiver

Transmitter

Audio Frequency Response : 50-15KHz

Dynamic range :≥100dB

System distortion:≤0.5%

S/N Ratio :≥100dB

Operating range : 80M

Operating temperature Range: 10℃-55℃

Carrier frequency: 180-280MHz

Sensitivity (S/N=30dB): < 2μ V

Image rejection: >50dB

De-Emphasis: 50μS

Audio Output Impedance: 600 Ω ± 10%

Audio Output level: 0-0.5V

Power supply: AC 110-220V

Current consumption: 4.5W

Dimensions: 423*220*58mm

Weight: Appr. 1750g

Frequency stability: ±0.005%

RF Output power: ≤30mW

Spurious rejection: > 50dB

Modulation mode: FM

Max deviation range: ± 25KHz

Microphone mode: Dynamic

De-Emphasis: 50μS

Power supply: 4.5V

Current Consumption: <30mA

Dimensions: 53*250mm

Weight:.235g
