Overall System

Receiver

Transmitter

Audio Frequency Response : 80-12KHz

Dynamic range :≥80dB

System distortion:≤2%

S/N Ratio :≥80dB

Operating range : 50M

Operating temperature Range: 5℃-45℃

Carrier frequency: 180-280MHz

Sensitivity (S/N=30dB): <8μ V

Image rejection: >50dB

De-Emphasis: 50μS

Audio Output Impedance: 600 Ω

Audio Output level:0-0.5V

Power Supply: AC220V

Current consumption: <500mA

Dimensions: 210*145*44mm

Weight: Appr. 398g

Frequency stability: ±0.005%

RF Output power: ≤30mW

Spurious rejection: >40dB

Modulation mode: FM

Max deviation range: ±50KHz

Microphone mode: Dynamic

De-Emphasis: 50μS

Power supply: 9V

Current Consumption: <35mA

Dimensions: 37(D)*250(L)mm

Weight:.190g
