176－264VAC

47-63Hz

◆ AC inrush current：

 Cold start, 40A/230VAC

◆ DC adjustment range：

±5%

◆ Line regulation (full load)：

≤±0.5%

◆ Output over load protection：

110%-150% hiccup mode, auto-recovery

◆ Rise, hold up time：

50mS, 20mS (typical)

◆ Withstand voltage：

I/P-O/P, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC, 1min

◆ Working temperature：

0-40℃@100%,  -10℃@80%, 50℃@60%load

◆ Storage temperature：

-20℃~+85℃, 20%~95%RH (non condensing)

◆ Safety standards：

Design refer to GB4943, UL60950, EN60950

◆ EMC standards：

Design refer to GB9254, EN55022 class A

◆ Cooling method：

Free air cooling convection

◆ Weight：

0.15Kgs/pcs

Product Model

DC Output

Load Regul.

R&N

Efficiency

SPW120-12

12V, 10A

0.5%

80mV

72%

SPW120-15

15V, 8A

0.5%

100mV

73%

SPW120-24

24V, 5A

0.5%

100mV

76%

SPW120-36

36V, 3.3A

0.5%

100mV

76%

SPW120-48

48V, 2.5A

0.5%

150mV

78%
