| Code: | YD385-17B |  |
| Name: | 15'' woofer, Alu frame, 300W(RMS) |
 |
| Model | YD385-17B |
| Power rating (RMS) | 300w |
| Impedance (Ω) | 6.0Ω |
| Frequency range (Hz) | 35Hz~2500Hz |
| Sensitivity (1W/1M) | 89.2dB±3dB |
| Frame | Alu frame, black |
| Magnet (mm) | Φ190*89*20 Y30 |
| Voice coil (mm) | Φ76.5*75.5*H50mm |
| Weight | 7.4kgs |
| Size (mm) | Φ395*155 |
