| Code: | SPW-YD200-02C to SPW-YD460-02C |  |
| Name: | woofer |
 |
Specifications:
| SPW-YD200-02C to SPW-YD460-02C | Paper Cone With Foam Edge | ||||||
| Model | Size | Magnet | Voice Coil | Max Power (W) | Impedance | Freq | Sensitivity |
| SPW-YD200-02C | 8" | 100x60x20 (20oz) | 1" ASV | 150 | 4 or 8 ohm | 55-5kHz | 90 dB/w.m |
| SPW-YD250-02C | 10" | 120x60x20 (30oz) | 1.5" ASV | 200 | 4 or 8 ohm | 40-5kHz | 91 dB/w.m |
| SPW-YD300-02C | 12" | 140x70x20 (40oz) | 1.5" ASV | 250 | 4 or 8 ohm | 35-4kHz | 92 dB/w.m |
| SPW-YD385-02C | 15" | 170x80x20 (65oz) | 2" ASV | 280 | 4 or 8 ohm | 25-4kHz | 93 dB/w.m |
| SPW-YD460-02C | 18" | 190x90x20 (80oz) | 3" ASV | 300 | 4 or 8 ohm | 25-2kHz | 93 dB/w.m |
