| Code: | DVR-8404 |  |
| Name: | 4CH H.264 VGA iCloud full function |
 |
 FEATURES: |
| * H.264 Main Profile Compression Algorithm Ideal |
| * Supports 4/8/16-CH Real Time Recording / Playback Simultaneously |
| * Supprts VGA Output/HDMI option |
| * Simple GUI Menu Operation with Mouse right click Function Menu |
| * Supports iPhone 5/iPad 2,Blackberry,Android,Symbian and Windows mobile software compatibility |
| * Supports Windows XP,Vista,Womdpws 7 and OS X 10.6/10.7 system compatibility |
| * Supports Internet Explorer,Google Chrome ,Mozilla Firefox and Safari internet browser compatibility |
| * Multi-language menus option up to 28 kinds of Language |
| * Supports TCP/IP,DHCP,DDNS,PPPoE,UPNP,NTP,SMTP,FTP,RTSP,ARSP etc…network protocol |
| * Supports 1 SATA HDD up to 2TB each,2 USB 2.0 port for Mouse and Backup operation convenience |
| * Supports the Sound System for Protection Circuit, unique Triple Watchdog function,Low power |
| * Consumption,so that ensure the equipment never be hang up |
SPECIFICATIONS:
| Model | DVR-8404 | |||
| System | Main Processor | High performance embedded microprocessor Hi3515 | ||
| Operating System | Embedded LINUX | |||
| System Resources | Pentaplex function:live,recording,playback,backup & remote access | |||
| User Interface | GUI,on-screen menu tips | |||
| Video | Video System | PAL/NTSC | ||
| Video Compression | H.264 | |||
| Video Recording | D1:PAL 1f/s~25f/s,NTSC 1f/s~30f/s | |||
| Encode capacity | 100/120fps(D1) | |||
| Motion Detection | Zones:396(22*18)detection zones,Sensitivity:1~6(6 is highest) | |||
| Trigger recording,PTZ movement,tour,alarm,email,snapshot & FTP | ||||
| Audio | Audio Compression | G711A | ||
| Bidrectional Talk | Support | |||
| Record & Playback | Recording Mode | Manual/Alarm/Video Detection/Continuous | ||
| Playback | 1~4Channels playback simultaneously | |||
| Search Mode | Time/Date,Alarm,Motion Detection & exact search(accurate to second) | |||
| Storage & Backup | Space Occupation | Audio 28.8MB/H ;Video 25~450 MB/H | ||
| Record Storage | Local Hard disk and Network | |||
| Backup Mode | Network download/Flash stick/movable HDD/SATA HDD | |||
| Interface | Video Input | 4CH | ||
| Video Output | 1Channel TV output BNC; 1 VGA output | |||
| Audio Input | 4*RCA | |||
| Audio Output | 1*RCA | |||
| Alarm Input | 4CH | |||
| Alarm Output | 1CH | |||
| Net Interface | RJ45(10M/100M) | |||
| PTZ Control | 1*RS485 | |||
| USB Interface | 2*USB2.0 | |||
| Hard Disk | 1 SATA ports(Max 2048G) | |||
| Environmental | Power Supply | 12V/2A | ||
| Power Consumption | <10W(not include Hard disk) | |||
| Working Temperature | 0℃~+55℃ | |||
| Working Humidity | 10%~90% | |||
| Dimension(W*L*H) | 240* 330* 58mm | |||
| Weight | 1.4KG | |||
