| Code: | DVR-5016E |  |
| Name: | 16CH DVR H.264+VGA, remote view, iCloud |
 |
Specifications:
| Model | DVR-5016E | |||
| System | Main Processor | High performance embedded microprocessor Hi3520A | ||
| Operating System | Embedded LINUX | |||
| System Resources | Pentaplex function:live,recording,playback,backup & remote access | |||
| User Interface | GUI,on-screen menu tips | |||
| Video | Video System | PAL/NTSC | ||
| Video Compression | H.264 | |||
| Video Recording | D1:PAL 25f/s,NTSC 30f/s | |||
| Encode capacity | 100/120fps(D1) | |||
| Motion Detection | Zones:396(22*18)detection zones,Sensitivity:1~6(6 is highest) | |||
| Trigger recording,PTZ movement,tour,alarm,email,snapshot & FTP | ||||
| Audio | Audio Compression | G711A | ||
| Bidrectional Talk | Support | |||
| Record & Playback | Recording Mode | Manual/Alarm/Video Detection/Continuous | ||
| Playback | 1~16Channels playback simultaneously | |||
| Search Mode | Time/Date,Alarm,Motion Detection & exact search(accurate to second) | |||
| Storage & Backup | Space Occupation | Audio 28.8MB/H ;Video 25~450 MB/H | ||
| Record Storage | Local Hard disk and Network | |||
| Backup Mode | Network download/Flash stick/movable HDD/SATA HDD | |||
| Interface | Video Input | 16CH | ||
| Video Output | 1Channel TV output BNC; 1 VGA output | |||
| Audio Input | 2*RCA | |||
| Audio Output | 1*RCA | |||
| Net Interface | RJ45(10M/100M) | |||
| PTZ Control | 1*RS485 | |||
| USB Interface | 2*USB2.0 | |||
| Hard Disk | 1 SATA ports(Max 2048G) | |||
| Environmental | Power Supply | 12V/2A | ||
| Power Consumption | <10W(not include Hard disk) | |||
| Working Temperature | 0℃~+55℃ | |||
| Working Humidity | 10%~90% | |||
| Dimension(W*L*H) | 245*236*42mm | |||
| Weight | 1.0KG | |||
