Image Sensor

1/4" Sharp CCD                      1/3" Sony CCD

Horizontal Resolution

420TV Line                          480TV Line

System

PAL:500(H)×582(V)             PAL:752(H)×582(V)

NTSC:510(H)×492(V)            NTSC:768(H)×492(V)

Minimum Illumination

0.8 Lux (F=1.2)

White Balance

Auto

BLC

Auto

Electronic Shutter

PAL=1/50-1/100,000sec;NTSC=1/60-1/100,000sec

Lens

f=3.6mm/F2.0

S/N Ratio

More than >48dB(AGC off)

Operation Temperature

-10℃~+60℃ (Relative Humidity 95% max.)

Storage Temperature

-20℃~+50℃ (Relative Humidity 95% max.)

Video Output

BNC 1.0VP-P,75Ω

Power Supply

DC12V±5%

Power Consumption

80mA
