| Code: | IP-613A-M181 |  |
| Name: | Wireless IP camera, M-JPEG, 300,000 pixel |
 |
Wireless IP Camera;
1)white,CMOS,f=3.6mm,IR LedФ5mm*8pcs,100*67*84mm,130g;
2)M-JPEG;
3)microphone,with silver Alu bracket,wifi;
4)power adaptor DC5V 2.0A;
Functions;
◎ 300,000 pixels CMOS sensor, F=2.0 f=4.5mm
◎ M-JEPG compression format, support VGA/QVGA/QQVGA
◎ One-way audio function with build-in mic
◎ Wi-Fi, 802.11 B/G, support both wired and wireless
◎ 8pcs IR LED, night vision of 5-8m
◎ Motion detection function and with alarm input port
◎ Support E-mail and FTP alarm
◎ Support 3 level user authorities
◎ With manufacturer DDNS to directly view via Browsers
◎ Free 64-CH CMS for multi-view
Specifications;
| Features | System security | Supports three-level account, password, user multi-level authority management |
| DDNS（free） | Built in free DDNS system,like http://demo.easyn.hk,'demo' is serial code | |
| Cellphone platform(free) | No need to install software, support multi-channel monitor &management& message alarm setting | |
| Super client | 1,4,9,16,25,36, 64-channel , no user limited , centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm,meeage alarm etc. | |
| Superiority | Support multi-channel monitor via cellphone or computer,certified by Microsoft activeX, support most of intelligent phone(such as Iphone,Antroid,Symbian ) | |
| CPU | Operation system | Embedded Linux OS |
| Microcomputer processor | 32Bit RSIC Embedded Processor | |
| Video | Compression format | Motion-JPEG-N |
| Signal system | CMOS 300,000 pixel | |
| Frame rate | 25fps | |
| Resolution | VGA(640*480), QVGA(320*240) | |
| Image adjustment | Brightness, contrast, saturation. | |
| WB, BLC | Auto | |
| Lens | Standard: 3.6mm | |
| Night Vision | nightvision | 8Φ5 LED lights IR distance: 10m |
| Audio | Compression format | ADPCM |
| Input | Built-in Mircophone | |
| Output | Video output | |
| Audio gain | AGC | |
| Network | Network interface | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Protocol | Support TCP/IP、HTTP、ICMP、DHCP、FTP、SMTP、PPPoE etc. | |
| Wireless | WIFI,802.11 b/g | |
| Online visitor | Support 4 visitors at the same time | |
| IP mode | Dynamic IP address, static IP address, PPPOE | |
| Others | Shape | Cartoon robot |
| Use environment | Indoor use | |
| Power | DC5V 2A | |
| Temperature | -10~50 °C | |
| Humidity | 95% RH | |
| Size | Item size:100*85*65mm( L*W*H) Package size:145*145*90mm（L*W*H） | |
| Weight | G.W.: 128g（Note:for real products ） | |
| Attachment | Power adapter ,CD, manual ,bracket, screws,warranty card | |
| Alarm | Alarm detection | Built-in motion detection, sensitivity can be set |
| Alarm action | Support Email photo ,FTP photo upload ,preset positions call , GPIOetc. | |
| System | System requirement | Microsoft Win98 SE/ME/2000/XP、Vista、Win 7, Internet Explorer 8.0, FireFox，Google Browser |
| Certification | Certificate | ISO FCC CE SASO RoHS |
