| Code: | IP-691A-M186 |  |
| Name: | Wireless IP camera, H.264/M-JPEG, 300,000pixel, scanner motor |
 |
Wireless IP Camera;
1)purple,CMOS,f=3.6mm,IR LedФ5mm*9pcs,105*116*130mm,276g 32G SD;
2)H.264,M-JPEG;
3)with scanner motor,microphone,spurple bracket,wifi,32G SD;
4)power adaptor DC5V 2.0A;
Specifications;
| Features | System security | Supports there-level account, password, user multi-level authority management |
| DDNS（free） | Built in free DDNS system,like http://demo.easyn.hk,'demo' is serial code | |
| IE multi-channel view client(free) | No need to install software, support multi-channel monitor &management & check alarm picture via IE | |
| Local memory | Support up to 32G SD card memory( SD card is not included) | |
| CPU | Operation system | Embedded Linux OS |
| Microcomputer processor | 32Bit RSIC Embedded Processor | |
| Video | Compression format | H.264 main profile level 3,dual stream |
| Signal system | PAL or NTSC | |
| Frame rate | Main stream:1-25fps second stream:1-25fps | |
| Resolution | VGA(640*480),QVGA(320*240) | |
| Video adjustment | Brightness, contrast, saturation. | |
| Minimum illumination | 0.3 Lux/F1.2 | |
| S/N ratio | >48DB (AGC off) | |
| Shutter speed | 1/50s-1/100,000s | |
| WB,BLC | Auto | |
| Lens | Standard: 3.6mm | |
| Nightvision | Filter switch | Built-in IR Cut,filter switch automatically, without color cast |
| Nightvision | 9 Φ5 LED lights IR distance: 10m | |
| Audio | Compression format | G.726/G.711 |
| Input | one channel linear input /mircrophone input | |
| Output | Audio output | |
| P/T | Motor | Built-in motor control |
| Rotation angle | Horizontal: 270° vertical: 90° | |
| Network | Network interface | 10Base-T/100Base-TX Ethernet slot |
| Protocol | TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc. | |
| Wireless | WIFI, 802.11 b/g | |
| Online visitor | Support 10 visitors at the same time | |
| IP mode | Dynamic IP address, static IP address, PPPOE | |
| Others | Material | Plastic |
| Use enviroment | Indoor use | |
| Power | DC5V 2A | |
| Temperature | -10~50 °C | |
| Humidity | 95% RH | |
| Size | Item size:125*105*130mm (LxWxH) Packaging size: 170*170*170mm (LxWxH) |
|
| Weight | G.W.: 730g (Note: for real products ) | |
| Accessories | Power adapter,CD,manual,warranty card,bracket,srews | |
| Alarm | Motion detection regions | support 4 Motion detection regions |
| Alarm action | Support Email photo、FTP photo、FTP record ,photo and record can be written into SD card | |
| System | System requirement | Microsoft Win98 SE/ME/2000/XP,Vista IE5.0, NET4.5,firefox,chrome |
| Certification | Certificate | ISO FCC CE SASO RoHS |
