| Code: | IP-4102-3.6 |  |
| Name: | Wireless IP camera, M-JPEG, 300,000 pixel, scanner motor |
 |
Specifications:
| Item | Sub Item | Description |
| Image Capture | Sensor | CMOS sensor |
| Total of pixel | 300k | |
| Minimum illumination | IR on，0 Lux | |
| Lens | f=3.6mm, F=2.0, Fixed Iris | |
| Pan/Tilt | Pan Coverage | 270° |
| Tilt Coverage | 120° | |
| Assistant | Lighting | 10pcs 850nm Infrared LEDs, 5m distance |
| Lighting Control | Auto control | |
| Video and Audio | Resolution | 640*480(VGA)/320*240(QVGA)/160*120(QQVGA) |
| Compression | MJPEG | |
| Frame rate | 30fps | |
| Bit rate | 128kbps ~ 5Mbps | |
| Image Rotation | Mirror /Flip | |
| Audio Compression | ADPCM | |
| Network | Basic Protocol | TCP/IP、UDP/IP、HTTP、SMTP、FTP、DHCP、DDNS、UPNP、NTP、PPPOE |
| Other Protocol | 802.11b/g | |
| Other Features | Video control | support |
| Dual way audio | support | |
| Motion Detection | support | |
| Triggered Actions | Email/FTP/external alarm/send message to alarm server | |
| User Setting | Three levels | |
| Date/ Time Setting | support | |
| Upgrade | Upgrade from network | |
| DDNS | A free DDNS provided by manufacturer | |
| Hardware Interface | Ethernet | 10Base-T/100base-TX |
| Alarm In | 1 way | |
| Alarm Out | 1 way | |
| Audio In | Internal mic | |
| Audio Out | Audio Line-out interface x 1 | |
| Physical Index | Weight | 245g |
| Main body | 100mm(L)*99mm(W)*118mm(H) | |
| Power | DC 5V | |
| Power consumption | <6W | |
| Operating temperature | -20℃~ 50℃ | |
| Operating temperature | 10% ~ 80% non-condensing | |
| Software(PC Side) | OS Supported | Microsoft Windows 98/2000/XP/Vista etc. |
| Browser | Internet Explorer6.0 and Above or Compatible Browser, Firefox, Safari etc. | |
| Application Software | IPCMonitor.exe |
