Image Sensor

1/4" Sharp CCD

1/3" Sony CCD

Horizontal Resolution

420TV Line

480TV Line

System

PAL:500(H)×582(V)

NTSC:510(H)×492(V)

PAL:752(H)×582(V)

NTSC:768(H)×492(V)

Minimum Illumination

0.1 Lux (F=1.2)

Lens

4mm（6mm, 8mm）

Backlight Compensation

On

Electronic Shutter

PAL=1/50-1/100,000sec;NTSC=1/60-1/100,000sec

Lens Angle

83°~36°

BLC

On

White Balance

Auto

S/N Ratio

>48dB

Gamma

>0.45

Operation Temperature

-10℃~+60℃ (Relative Humidity 95% max.)

Storage Temperature

-20℃~+50℃ (Relative Humidity 95% max.)

Video Output

BNC 1.0VP-P, 75Ω

Power Supply

DC12V±5%<150mA

Dimensions

87×67mm（Φ×H）

Weight

120g
