| Code: | Bipolor wire type |  |
| Name: |
 |
Bipolor wire type
| WV(V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 | |
| Cap(μF) | |||||||||
| 0.47 | - | - | - | - | - | 5x11.5 | - | - | |
| 1 | - | - | - | - | - | 5x11.5 | - | - | |
| 2.2 | - | - | - | - | - | 5x11.5 | - | - | |
| 3.3 | - | - | - | - | - | 5x11.5 | - | - | |
| 4.7 | - | - | - | - | - | 5x11.5 | - | - | |
| 5.6 | - | - | - | - | - | - | - | 5x11.5 | |
| 8.2 | - | - | - | - | - | - | - | 5x15 | |
| 10 | - | - | - | - | - | 5x11.5 | - | - | |
| 12 | - | - | - | - | - | 5x11.5 | 5x11.5 | 6.3x11.5 | |
| 18 | - | - | - | - | - | 5x11.5 | 5x15 | 6.3x15 | |
| 22 | - | - | - | - | - | - | - | 8x12 | |
| 27 | - | - | - | - | 5x11.5 | 5x15 | 6.3x11.5 | 10x12.5 | |
| 33 | - | - | - | - | - | - | - | 8x15 | |
| 39 | - | - | - | 5x11.5 | 5x15 | 6.3x115 | 6.3x15 | 8x20 | |
| 47 | - | - | - | - | - | - | 8x12 | - | |
| 56 | - | - | 5x11.5 | 5x15 | 6.3x115 | 6.3x15 | - | 10x20 | |
| 68 | - | - | - | - | - | 8x12 | 8x15 | 10x25/12.5x20 | |
| 82 | - | 5x11.5 | 5x15 | 6.3x11.5 | 6.3x15 | 8x15 | 8x20 | - | |
| 100 | 5x11.5 | 5x15 | - | - | - | 10x16 | - | 10x30 | |
| 120 | - | - | 6.3x11.5 | 6.3x15 | 8x12 | 8x20 | 10x20 | 12.5x25 | |
| 150 | 5x15 | - | - | - | - | - | 10x2512.5x15 | 18x15 | |
| 180 | - | 6.3x11.5 | 6.3x15 | 8x12 | 8x15 | - | - | 12.5x30 | |
| 220 | 6.3x11.5 | 6.3x15 | - | 8x15/10x12.5 | 8x20 | 10x25 | 12.5x20 | 12.5x35/16x25 | |
| 270 | - | - | 8x12 | 10x16 | - | - | 12.5x25 | 12.5x40/18x20 | |
| 330 | 6.3x15 | 8x12 | 8x15/10x12.5 | 8x20 | 10x20 | 10x30 | - | 16x31.5/18x25 | |
| 390 | - | - | - | - | - | - | - | - | |
| 470 | 8x12 | 8x15/10x12.5 | 8x20 | 10x20/12.5x15 | 12.5x30 | 18x15 | 12.5x35/16x25 | 16x40 | |
| 680 | 8x15 | 8x20 | 10x20 | - | 12.5x30 | 12.5x35/16x20 | 16x31.5/18x25 | 18x40 | |
| 820 | 10x16 | - | 10x25 | 16x15 | - | 16x25/18x20 | 16x35.5/18x31.5 | - | |
| 1000 | 8x20 | 10x20 | - | 12.5x25 | 12.5x25 | 16x31.5 | 16x40 | - | |
| 1200 | 10x20/12.5x15 | 10x25 | 10x30 | 18x15 | 16x25/18x20 | 16x35.5 | 18x40 | - | |
| 1500 | 10x25 | 10x30 | 12.5x25/16x15/18x15 | 12.5x30/16x20 | 12.5x40 | 16x40/18x31.5 | - | - | |
| 1800 | - | 12.5x20/16x15 | - | 12.5x35/16x25/18x20 | 18x25 | 18x35.5 | - | - | |
| 2200 | 10x30 | 12.5x25/18x15 | 12.5x30/16x20 | 12.5x40 | 16x35.5/18x31.5 | 18x40 | - | - | |
| 2700 | 12.5x25/16x15 | 12.5x30 | 12.5x35/18x20 | 16x31.5/18x21.5 | 18x35.5 | - | - | - | |
| 3300 | 18x15 | 12.5x35/16x20 | 12.5x40 | 16x35.5/18x35.5 | 18x40 | - | - | - | |
| 3900 | 12.5x30 | 12.5x40/16x25/18x20 | 16x31.5/18x25 | 16x40 | - | - | - | - | |
| 4700 | 12.5x35/16x20 | 18x25 | 16x35.5/18x31.5 | - | - | - | - | - | |
| 6800 | 16x31.5 | 16x35.5/18x31.5 | 18x35.5 | - | - | - | - | - | |
| 8200 | 16x35.5 | 16x40 | - | - | - | - | - | - | |
| WV(V) | 160 | 200 | 250 | |
| Cap(μF) | ||||
| 4.7 | - | 10x12.5 | 10x12.5 | |
| 10 | 10x16 | 10x16 | 10x20 | |
| 22 | 10x20 | 10x20 | 12.5x25 | |
| - | - | 16x20 | ||
| 33 | 12.5x20 | 12.5x20 | 12.5x25 | |
| - | - | 16x20 | ||
| 47 | 12.5x25 | 12.5x25 | 16x25 | |
| 16x20 | 16x20 | 18x20 | ||
| 100 | 16x25 | 16x31.5 | 16x31.5 | |
| 18x20 | 18x25 | 18x25 | ||
| 220 | 18x35.5 | - | - | |
| WV(V) | 350 | 400 | 450 | |
| Cap(μF) | ||||
| 1.0 | - | - | 10x12.5 | |
| 2.2 | - | 10x12.5 | 10x16 | |
| 3.3 | 10x12.5 | 10x16 | 10x20 | |
| 4.7 | 10x16 | 10x20 | 12.5x20 | |
| 10 | 12.5x20 | 12.5x20 | 16x20 | |
| 22 | 12.5x25 | 16x25 | 16x31.5 | |
| 16x20 | 18x20 | 18x25 | ||
| 33 | 16x25 | 16x31.5 | 18x35.5 | |
| - | 18x25 | - | ||
| 47 | 16x35.5 | 18x31.5 | - | |
| 18x31.5 | - | - | ||
