FEATURES

● 4 channels stereo DJ mixer

● 8 Line/2 Phono/4 MIC input

● AMP, Booth and REC output

● Dual bands 10 digits LED level display

● Dual 10-band graphic equalizer

● Built-in 6-audio effects

● DC12V BNC lamp jack

 INPUT LEVEL

● MIC:1.5mV/600Ω balanced

● Phono:3mV/50kΩ

● Line:150mV/27kΩ

● Return EFX:500mV/10KΩ

 OUTPUT LEVEL

● Master:2V/10kΩ

● Record:2V/10kΩ

 MIC EQ CONTROL

● High:10 kHz/±12dB

● Low:80Hz/±12dB
