FEATURES

●　LED indicator

●　4 Line/2 Phono/2 MIC input select

●　Master, AUX and REC output

●　Dual bands 10 digits LED level display

●　Dual 7-band graphic equalizer

●　24 second digital sampling control

●　Record/Single Play/Circle Play, speed

●　adjustable for different effects

●　DC12V BNC lamp jack

 INPUT LEVEL

●　MIC1:1.5mV/600Ω balanced

      MIC2:1.5mV/600Ω unbalanced

●　Phono:3mV/50kΩ

●　Line:150mV/27kΩ

 OUTPUT LEVEL

●　Master:2V/10kΩ

●　Record:1V/10kΩ

 MIC EQ CONTROL

●　High:10 kHz/±12dB

●　Low:80Hz/±12dB
