| Code: | RMX3000 RMX5000 |  |
| Name: | professional amplifier RMX series |
 |
Features:
● Graceful tone & performance by use of Toshiba transistor
● Latest appearance, exquisite workmanship and reliable quality
● Higher class amplifier with H circuit for 1000W and AB circuit below 600W
● Perfect circuit protections such as over heat, over load, short-cut protection, anti-shock and DC output protection
● Limiter offers maximum output and protects speaker effectively
● Soft starting prevents surge shock
● Turn on delaying and turn off soundless
● Original Neutrik XLR and SPEAKON connectors
Specifications:
| Model | RMX3000 | RMX5000 | |
| Power output (W) 1KHz,0.5%THD+N |
Stereo 8Ω | 600W | 1000W |
| Stereo 4Ω | 1000W | 1800W | |
| Bridged Mono 8Ω | 2400W | 3800W | |
| Frequency response(1W@8Ω) | 15Hz-15kHz +0/-1dB | ||
| THD+N(Continuous power, 8Ω/1kHz) | ≤0.03% | ||
| S/N rate (20Hz-20kHz full load) | ≥100dB | ||
| Slew rate | 40V/us | ||
| Damping factor | ≥400:1 | ||
| Cross talk | ≥80dB | ||
| Input impedance | 20KΩ(Balance) /10KΩ(Unbalance) | ||
| Input sensitivity | 0.7V/1.0V/1.44V | ||
| CMRR | ≥68dB | ||
| Voltage gain(@1.44V/1V/0.775V) | 50X/70X/100X | 64X/90X/128X | |
| Input compression ratio | 18:1 | ||
| Dimension(WxDxH) | 483(19")mmx490mmx133(3U)mm | ||
| Weight | 27kg | 34kg | |
