FEATURES:

● 2 channels, triple rack space

● Two 31-band, 1/3 octave constant Q frequency bands

● Feedback alarm function, the LED turn on when alarm

● Balanced/unbalanced (XLR and 1/4'' TRS) input/output connectors

● Switchable boost/cut ranges of ±6 or ±12dB

● Parallel filter design for minimal phase distortion

● Low-cut filter at 40Hz, 12dB/octave, switchable, with status LED

● Variable input level control ±15dB

● Equalizer ON/OFF bypass switch with LED status

● Dynamic range greater than 108dB

● Internal shielded transformer

● Compact and durable all-steel chassis design

 SPECIFICATIONS:

● Frequency Bands: 2*31, 1/3 octave, ISO spacing

● Slider Travel: 20mm (Center Detent)

● Input Impedance: Balanced 40kΩ, unbalanced 20kΩ

● Input Max Level: 28dBu

● Output Max Level: 21dBu

● Output Impedance: Balanced 100Ω, unbalanced 50Ω

● Frequency Response: 10Hz~50 kHz, 0.5/-1dB

● Bandwidth: 20Hz~20 kHz, 0.5/-1 dB

● S/N Ratio: >95dB

● Dynamic Range: >108dB

● THD: <0.003% (1 kHz)

● Inter channel Crosstalk:<-90dB, 20Hz~20 kHz

● Power Supply: AC220V 50Hz
