FEATURES

● 2 channels, triple rack space

● Two 31-band, 1/3 octave constant Q frequency bands

● Noise Reduction capable of restoring up to 20dB S/N ratio

● Proprietary patent-pending Peak plus Limiter for system protection

● Balanced/unbalanced inputs and outputs

● XLR, barrier strip and 1/4'' TRS input/output connectors

● Switchable boost/cut ranges of ±6 or ±15dB

● Parallel filter design for minimal phase distortion

● 18dB/octave 40Hz Bessel low-cut filter

● Variable input level control ±12dB

● Internal switching power supply

● Compact and durable all-steel chassis design

 SPECIFICATIONS

● Frequency Bands: 2*31, 1/3 octave, ISO spacing

● Slider Travel: 45mm (Center Detent)

● Input Impedance: Balanced 40kΩ, unbalanced 20kΩ

● Input Max Level: 21dBu

● Output Max Level: 21dBu

● Output Impedance: Balanced 100Ω, unbalanced 50Ω

● Frequency Response: 10Hz~50 kHz, 0.5/-1 dB

● Bandwidth: 20Hz~20 kHz, 0.5/-1 dB

● S/N Ratio: >94dB

● Dynamic Range: >108dB

● THD: <0.04% (1 kHz)

● Interchannel Crosstalk:<-80dB, 20Hz~20 kHz

● Power Supply: AC220V 50Hz
