Overall System

Receiver

Transmitter

Audio Frequency Response : 80-12000Hz

Dynamic range :≥80dB

System distortion:≤1%

S/N Ratio :≥80dB

Operating range : 80M

Operating temperature Range: -5℃-45℃

Carrier frequency: 480-560MHz

Receiving system: Diversity receiver

Sensitivity (S/N=30dB): 2μV

Image rejection: >50dB

De-Emphasis: 50μS

Audio Output Impedance: 600 Ω

Audio Output level:0-0.5V

Power Supply: DC13 V

Current consumption: 5W

Dimensions: 195*125*40mm

Weight: Appr. 400g

Frequency stability: ±0.005%

RF Output power : ≤30mW

Spurious rejection: >40dB

Modulation mode: FM

Max deviation range: ± 25KHz

Microphone mode: Dynamic

De-Emphasis: 50μS

Power supply: 9VBatt

Current Consumption: <50mA

Dimensions:38(D)*240(L)mm

Weight:. 330g
