| Code: | YD255-779 |  |
| Name: |
 |
Specifications:
| Mode | YD255-779 |
| Rated Power(W) | 120 |
| Impedance(Ω) | 8 |
| Frequency Range(Hz) | 40~1800 |
| Sensitivity(dB) | 94 |
| Total Quality Factor(Qts) | 0.26 |
| Electrical Quality Factor(Qes) | 0.27 |
| Mechanical Quality Factor(Qms) | 5.85 |
| Voice Coil Diameter(Φmm) | 49.5 |
| Magnet Size(mm) | 120*20 & 110*20 |
| Speaker Size(Inch) | 10 |
| Dimension(Φ*H mm) | 255*140 |
