| Code: | YD200-7 |  |
| Name: |
 |
Specifications:
| Mode | YD200-7 |
| Rated Power(W) | 80 |
| Impedance(Ω) | 4 |
| Frequency Range(Hz) | 40~3500 |
| Sensitivity(dB) | 91 |
| Total Quality Factor(Qts) | 0.43 |
| Electrical Quality Factor(Qes) | 0.47 |
| Mechanical Quality Factor(Qms) | 5.05 |
| Voice Coil Diameter(Φmm) | 35.5 |
| Magnet Size(mm) | 100*20 & 100*18 |
| Speaker Size(Inch) | 8 |
| Dimension(Φ*H mm) | 210*119 |
