| SP212 |
|
| 2x12INCH HIGH EFFICIENCY SUBWOOFER |
| |
|
| FEATURES |
|
| ★ |
SPL up to 133dB/1M |
| ★ |
Base reflex design brings high efficiency and deep punch |
| ★ |
High sensitivity 96dB |
| ★ |
25mm Russian birch wood cabinet |
| ★ |
Waterproof perforated grill |
| ★ |
Smart,fast and safe rigging system for fixed installation and touring |
| |
|
| APPLICATIONS |
| ★ |
SPL up to 133dB/1M |
| ★ |
Base reflex design brings high efficiency and deep punch |
| ★ |
High sensitivity 96dB |
| ★ |
25mm Russian birch wood cabinet |
| ★ |
Waterproof perforated grill |
| ★ |
Smart,fast and safe rigging system for fixed installation and touring |
| |
|
| SPECIFICATIONS |
| SYSTEM PARAMETER |
| Frequency Response |
42Hz-120Hz (+3 dB ) |
| Usable Frequency |
35Hz-120Hz (-10dB ) |
| SPL |
127dB continuous , 133dB peak |
| Power Rated(AES) |
1200W |
| Impedance |
Nominal Impedance:4 ohm |
| Sensitivity |
Sensitivity: 96dB (42-120Hz) |
| SPECIFICATIONS |
| LF |
12"woofer, 4"voice coil. |
| Impedance:8 ohm Power Rated:600W (AES) |
| Max power:1200W |
| Dimension |
716mm(W)x357mm(H)x557mm(D) |
| Enclosure |
Support for hanging installation, waterproof paint finish, with 2 handles |
| Weight |
53KG |
| Connector |
2X SPEAKON 4pole(input ¶llel connection) connector:2+&2- |
| Texture |
Russian birch plywood, waterproof big-spot paint |
| Handle: wooden handle on both sides |
| Grill: black iron grill attached a stainless thin grille to keep out of the corrosiveness of rain |
| Fittings |
Flying points: heat treated aluminum, Front Fittings are fixed connection, and back fittings have several hole options for selection by angle from 0° to 10°with 1°. The load bearing of the flying kits and accessories are qualified with 7 :1 safety factor. |
