| SP218 |
|
| 2×18" high efficiency subwoofer |
|
| |
|
|
| FEATURES |
|
|
| ★ |
Compact cabinet design,Phase inverted enclosure with SPLup to 136dB/1m. |
| ★ |
Direct-radiating woofer to obtain greater effictency and lower frequency expand. |
| ★ |
25mm Russian birch wood cabinet |
| ★ |
Waterproof perforated grille. |
| ★ |
Smart,fast and safe rigging system for fixed installation and touring. |
| |
|
|
| APPLICATIONS |
|
|
| |
SP line array series are designed for large venues,clubs or outdoor events. |
| |
|
|
| SPECIFICATIONS |
|
| |
Transducer |
| Frequency Response (±3 dB) |
30Hz-200kHz |
| Usable Frequency (-10 dB) |
25Hz-250Hz |
| SPL |
136dB peak |
| Sensitivity |
99dB |
| Power handling |
1400W |
| Nominal Impedance |
4 Ω |
| Enclosure |
Phase inverted |
| TRANSDUCER SECTIONS |
| Drivers |
2*18'' Subwoofers |
| Enclosure |
Russian birch plywood,waterproof big-spot paint |
| Connector |
2*SPEAKON 4 pole (Input & link) |
| Handle |
Both sides with a two-way aluminum handle,placed center of gravity |
| Grille |
Iron grille attached a stainless thin grille to keep out of the corrosiveness of rain |
| |
Dimensions (HxWxD) |
553*1109*820mm |
| |
Net weight |
84kg |
