| Code: | SPW-YD200-05C to SPW-YD460-05C |  |
| Name: | woofer |
-05C.jpg) |
Specifications:
| SPW-YD200-05C to SPW-YD460-05C | Paper Cone With Foam Edge | ||||||
| Model | Size | Magnet | Voice Coil | Max Power (W) | Impedance | Freq | Sensitivity |
| SPW-YD200-05C | 8" | 120x60x20 (30oz) | 1.5" ASV | 250 | 4 or 8 ohm | 55-5kHz | 92 dB/w.m |
| SPW-YD250-05C | 10" | 140x70x20 (40oz) | 1.5" ASV | 300 | 4 or 8 ohm | 40-5kHz | 93 dB/w.m |
| SPW-YD300-05C | 12" | 156x70x20 (50oz) | 2" ASV | 350 | 4 or 8 ohm | 35-4kHz | 93 dB/w.m |
| SPW-YD385-05C | 15" | 190x90x20 (80oz) | 2.5" ASV | 400 | 4 or 8 ohm | 25-4kHz | 94 dB/w.m |
| SPW-YD460-05C | 18" | 220x110x20 (100oz) | 3" ASV | 500 | 4 or 8 ohm | 25-2kHz | 94 dB/w.m |
