| Code: | SPW-YD166-03C to SPW-YD385-03C |  |
| Name: | woofer |
-03C.jpg) |
Specifications:
| SPW-YD166-03C to SPW-YD385-03C | Paper Cone With Foam Edge | ||||||
| Model | Size | Magnet | Voice Coil | Max Power (W) | Impedance | Freq | Sensitivity |
| SPW-YD166-03C | 6" | 100x45x18 (20oz) | 1" ASV | 100 | 4 or 8 ohm | 60-8kHz | 90 dB/w.m |
| SPW-YD200-03C | 8" | 113x60x20 (25oz) | 1" ASV | 150 | 4 or 8 ohm | 55-5kHz | 91 dB/w.m |
| SPW-YD250-03C | 10" | 120x60x20 (30oz) | 1.5" ASV | 250 | 4 or 8 ohm | 40-5kHz | 92 dB/w.m |
| SPW-YD300-03C | 12" | 140x70x20 (40oz) | 1.5" ASV | 350 | 4 or 8 ohm | 35-5kHz | 93 dB/w.m |
| SPW-YD385-03C | 15" | 170x90x20 (63oz) | 2" ASV | 400 | 4 or 8 ohm | 25-4kHz | 94 dB/w.m |
